cisco network gear Cisco ASR-9901-120G Router 16x1G 24x1/10G 2x100G ports Dual AC Power
SKU: 26526809256
cisco network gear

cisco network gear Cisco ASR-9901-120G Router 16x1G 24x1/10G 2x100G ports Dual AC Power

Sale price$21.56 Regular price$23.96
Save 10%

Pay in installments of $5.99 with ShopPay, AfterPay and Klarna

Shipping Estimate
USA
  • USA
  • CAN

Ships within 48 hours · Estimated delivery Jul 5 - Jul 10

Promo Codes Available:

For Your Every Summer RSVP, with Code: SUMMER15

Description

cisco network gear Cisco ASR-9901-120G Router 16x1G 24x1/10G 2x100G ports Dual AC PowerOverview The Cisco ASR 9901 Router is a compact yet powerful Provider Edge (PE) router, part of the Cisco ASR 9000 Series. This router sets a new standard for service density and scalability, making it ideal for large scale aggregation and carrier Ethernet transport networks. Its versatile capabilities reduce both capital and operating expenses, while the Cisco IOS XR 64 bit operating system ensures reliability and high availability . If youre seeking

Overview

The Cisco ASR 9901 Router is a compact yet powerful Provider Edge (PE) router, part of the Cisco ASR 9000 Series. This router sets a new standard for service density and scalability, making it ideal for large-scale aggregation and carrier Ethernet transport networks. Its versatile capabilities reduce both capital and operating expenses, while the Cisco IOS XR 64-bit operating system ensures reliability and high availability . If you’re seeking robust networking solutions

  1. High Capacity: The ASR 9901 delivers an impressive 456 Gbps of nonblocking, full-duplex fabric capacity in a Two-Rack-Unit (2RU) form factor .
  2. Integrated Ports:
    • 16x 1 Gigabit Ethernet (1G) ports
    • 24x Dual-Rate 1/10 Gigabit Ethernet (1/10G) ports
    • 2x 100 Gigabit Ethernet (100G) ports
  3. Versatility: You can mix and match various interface types (1G, 10G, 40G, and 100G) across the ASR 9901 chassis .
  4. Cisco IOS XR Software: It runs on the same Cisco IOS XR software image as other routers in the ASR 9000 Series, allowing standardization on the same operating system .
  5. Applications:
    • Layer 2 and Layer 3 aggregation
    • Data Center Interconnect (DCI)
    • Satellite Network Virtualization (nV) System mode
  6. MAC-SEC Encryption: The ASR 9901 supports industry-leading MAC-SEC encryption on all its port speeds .

Specifications

Category

Part Number or Specification

Chassis

ASR 9901

Integrated interfaces

16x1 GE, 24x 1/10 GE, 2x100 GE

Redundancy

Power supply and Fan redundancy

Power supply part number

●  A9K-1600W-AC
●  A9K-1600W-DC

Physical specifications

●  Height: 3.43 inches (8.7 cm)
●  Width: 17.32 inches (44 cm)
●  Depth: 23.62 inches (60 cm)
●  Weight of chassis: 47.62 lbs (21.6 kg)
●  Weight of fully configured (including 2 x power modules & 3x Fan trays) chassis 55.97 lbs (25.4 kg)

Power inputs

●  Worldwide ranging AC (90-265V; 50-60 Hz)
●  Worldwide ranging DC (-40V to -72V)

Power consumption

●  850 watts typical, 1100 watts maximum

Environmental conditions

●  Operating temperature: 41° to 104°F (5° to 40°C)
●  Storage temperature: -40 to 167°F (-40 to 75°C)
●  Relative humidity: 10 to 85%, noncondensing
●  Regulatory compliance

Environmental Specifications

Operating temperature (nominal)

41 to 104°F (5 to 40°C)

Operating temperature
(short-term)

23 to 131°F (-5 to 55°C)

Operating humidity (nominal) (relative humidity)

10 to 85%

Operating humidity
(short-term)

5 to 90%
Note: Not to exceed 0.024 kg water or dry air

Storage temperature

-40 to 158°F (-40 to 70°C)

Storage (relative humidity)

5 to 95%
Note: Not to exceed 0.024 kg water or dry air

Operating altitude

0 – 4000 m

Air flow

Front to Back

Compliance

Network Equipment Building Standards (NEBS)

Cisco ASR 9901 is designed to meet:

●  SR-3580: NEBS Criteria Levels (Level 3)
●  GR-1089-CORE: NEBS EMC and Safety
●  GR-63-CORE: NEBS Physical Protection
●  VZ.TPR.9205: Verizon TEEER

ETSI standards

Cisco ASR 9901 is designed to meet (qualification in progress):

●  EN300 386: Telecommunications Network Equipment (EMC)
●  ETSI 300 019 Storage Class 1.1
●  ETSI 300 019 Transportation Class 2.3
●  ETSI 300 019 Stationary Use Class 3.1
●  EN55022: Information Technology Equipment (Emissions)
●  EN55024: Information Technology Equipment (Immunity)
●  EN50082-1/EN-61000-6-1: Generic Immunity Standard

EMC standards

Cisco ASR 9901 is designed to meet:

●  FCC Class A
●  ICES 003 Class A
●  AS/NZS 3548 Class A
●  CISPR 22 (EN55022) Class A
●  VCCI Class A
●  BSMI Class A
●  IEC/EN 61000-3-2: Power Line Harmonics
●  IEC/EN 61000-3-3: Voltage Fluctuations and Flicker
●  EN 50121-4: Railway EMC

Immunity

Cisco ASR 9901 is designed to meet:

●  IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air)
●  IEC/EN-61000-4-3: Radiated Immunity (10V/m)
●  IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal)
●  IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)
●  IEC/EN-61000-4-5: Signal Ports (1kV)
●  IEC/EN-61000-4-5: Surge DC Port (1kV)
●  IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms)
●  IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m)
●  IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations
●  EN 50121-4: Railway EMC

Safety

Cisco ASR 9901 is designed to meet:

●  UL/CSA/IEC/EN 60950-1
●  IEC/EN 60825 Laser Safety
●  ACA TS001
●  AS/NZS 60950
●  FDA: Code of Federal Regulations Laser Safety
